Carbon Steel Tubes
Suraj Limited is a prominent manufacturer and exporter of Carbon Steel and Alloy Steel Cold Drawn Seamless Tubes & U Tubes, specializing in Hydraulic and Fuel Injection Tubes.
At Suraj Limited, we manufacture U-tubes for heat exchangers, condensers, pre-heaters, and other applications using the most modern in-house "U" bending equipment. These U-Tubes are produced in compliance with TEMA ‘R’, ‘C’, ‘B’ and other legal regulations or specifications.
We are Suraj Limited's as tube manufacturers in India to maintained position as India's top tube maker. Our team has illustrated through steadfast technology development and a fervent manufacturing methodology that we are capable of producing alloy steel & carbon steel seamless tube heat exchanger tubes with an immaculate surface finish, excellent anti-corrosion competence, maintaining closer spatial endurance, and be supplied after having completed all mandatory evaluation and another optional testing wherever customer demands, for which we have our R&D facilities.
Cold Finish Process
The mother hollow produced from the piercer, after surface treatment, is pointed on one end, and then drawn over plug through a die on a Draw Bench. The relative movement between stationary plug and the tube being pulled, results in a controlled elastic deformation of the steel, in room temperature. Consequently, the tube is reduced with a high degree of accuracy to the desired outer diameter and wall thickness. Next, the drawn tube is heat-treated in a controlled atmosphere to achieve the required surface and mechanical properties. Finally, the tube is straightened and quality checks like Hydrostatic Testing, Eddy Current Testing and Visual Dimensional Inspection are carried out to ensure that the final finished product meets the required specifications within the dimensional tolerances. After this, the pipe batch moves for final chemical and mechanical tests.
Our strengths
- Superior Quality: Achieved through scale-free tubes processed in our advanced Bright Annealing Furnace.
- Efficient Deliveries: We ensure rapid delivery and quick responses for shutdown projects.
- Lean Manufacturing: Our operations are guided by the principles of lean manufacturing for optimal efficiency.
- Extended Tube Lifespan: Our controlled atmosphere furnace eliminates the need for final-stage pickling in HCL acid, significantly enhancing tube longevity.
- Comprehensive Manufacturing: We offer a wide range of seamless tubes and pipes, including U-bend tubes, all produced under one roof.
Hydraulic tubes cater to the diverse needs of major diesel engine manufacturers, OEMs, and auto ancillaries.
Our precision seamless tubes for the automotive industry are produced using advanced cold drawing processes, adhering to ISO 8535-1 standards. Materials such as E235, E255, and E355 are delivered in NBK condition, ensuring high quality and consistency. The tubes are exclusively made from fully aluminum-killed steel to prevent aging-related issues like embrittlement and cracking.
Key features of our Hydraulic & Fuel Injection tubes include:
- Surface roughness below 2 microns Ra on the internal surface
- High precision in dimensional tolerance
- Superior surface brightness with no oxidation on both inner and outer walls post heat treatment
- Exceptional cleanliness of the inner wall
| Types | Straight Tubes, ‘U’ Tubes, Hydraulic & Fuel Injection Tubes |
|---|---|
| Outside Diameter | 6.00 mm to 114.00 mm |
| Wall Thickness | 0.80 mm to 6.00 mm |
| Grades | A/SA179, A/SA192, A/SA210, A/SA213 T2, T5, T11, T12, T22, T9, T91, ST37.4, ST52.4, A/SA106 Gr.B, A/SA53 Gr.B, API5L Gr.B, A/SA333 Gr. 1/6, A/SA334 Gr.1/3/6 A/SA335 P1, P2, P5, P11, P12, P22 |
| Specifications | ASTM, ASME, DIN EN, JIS ( JAPAN ), NF ( AFNOR ) |
| Length | Up to 30mtr long |
| Applications |
|
